There are over 300 communications satellites in the geostationary orbit, directly above the equator, spaced typically 2 or 3
degrees apart. Because they orbit the earth at the same speed and in the same direction as the earth rotates they remain fixed in the sky and you can
use a fixed pointing very small aperture terminal (VSAT) to communicate. The maximum possible coverage area from any one orbit position is approx one
third of the earth, as that is all that is visible from the orbit position at a height of 35726 km. For example, a

satellite above the equator to south of India can provide coverage which includes South Africa, Europe to Japan and Australia, as well as India which
is almost directly below it. To help with small dish operations spot beams are pointed down at particular areas. This web site
shows many such beam coverage areas. In general, smaller spot beams permit smaller earth station dishes.

The satellites are generally owned and operated by large international organisations, such as
Intelsat.

Eutelsat is an example of a European regional operator.

At the higher frequency Ka band, 20/30 GHz, there is a significant trend towards high throughput satellite (HTS) using small, multiple, spot beam design with the VSAT technology used (e.g. Viasat Surfbeam or HughesNet) all being determined by the satellite owner, with smaller
local reseller companies employed to essentially deliver “Satellite broadband” to end users customer, collect the money and resolve as much as possible of the
customer support locally.

Capacity is measured in amounts of transponder bandwidth (MHz) and downlink eirp power (dBW) and uplink G/T (dBK) and sensitivity (dBW/^m2) are sold to
satellite internet providers who have teleports with groups of large earth station dishes.  The conversion of bandwidth, measured in MHz, to
information data rate is complex and depends on modulation method (e.g BPSK, QPSK, 8-QAM or 16-QAM) and the forward error correction coding rate
(e.g 1/2, 3/4 or 7/8) and the type of FEC (e.g. Turbo Code, Viterbi, Low Density
Parity Check or  Reed Soloman or combination thereof).  The size of the dishes used also affects the achieved capacity.
Using a larger dish may markedly reduce costs per Mbit/s.

Satellite internet providers then deliver the service to end users by providing them with equipment and with monthly
download (Mbytes) capacity allowance, plus customer support.

Customer equipment consists of a small dish, from 60cm to 3.7m diameter, at least equipped with a receiver module (LNB definition = Low Noise Block
down-converter) and transmit module (BUC definition = Block Up-Converter).

See pictures of
typical customer VSAT installations. The indoor equipment receives the signals and extracts
data for the customer’s PC or local area network.

The indoor equipment also prepares data for transmission, typically in very brief
TDMA
bursts whenever the mouse is clicked to send a request to the internet.

[2008]Monthly bit rate rental is specified, for example, as 512k down / 64k up shared 20:1 at price $202 per month.  This price is per VSAT customer
terminal (i.e. $4032 per month in total).  Such a solution would suit 1 or 2 PCs per site.  When you are downloading a file the speed may be
up to 512k bit/s. With 50:1 sharing you would find that for much of the time the available bit rate is lower – as other people will be using the
capacity at the same time. In shared arrangements there are often monthly download and upload limits (measured in G bytes per month) per customer, so
that one user cannot block everyone else. Such fair-use or fair-access-policies
(FAP) policies can be complex and, for example, may allow 50 Mbytes to be downloaded at high speed
(say at 355 kbit/s) with such activity then followed by several hours of restricted lower speed 128kbit/s service until the service returns to high
speed at the end of the day. Such policies vary greatly from one provider to another.    When calculating the downlink bit rate capacity
required, allow 14 kbit/s per PC, so if you have 100 PCs in your local area network (LAN) you need at
least 1 Mbit/s dedicated download rate.
Uplink bit rates required are about 1/3rd of the downlink rate. If your use is only web browsing then the up/down ratio is about 1/5.  If you do
lots of VoIP calls then you need more equal capacity up and down.  Remember you
only get what you pay for.  As a rough estimate, for C and Ku bands, if you see a monthly
tariff, divide it by $70 and that will give you the number of PCs that you can connect in your LAN.  Don’t believe marketing hype about
“unlimited” downloads on what are, in reality, shared systems. For
lower cost Ka band such as

Wildblue

Tooway

Avanti-Hylas

Figures as low as $40 – $80 per month may apply for basic home satellite internet access.

[2014]Update on costs: 20 Mbit/s down + 10 Mbit/s up = $90,000 per month. “Up to 20 Mbit/s” shared between 1500 customers at $60 per month (each customer).

[2015]Use of older satellites in inclined orbit requires tracking antennas, e.g. 1.2m diameter.  The initial costs and maintenance cost of a tracking antenna can cost much more than for similar sized, fixed antenna, but the
satellite costs are lower, for example $600 per 1 Mbit/s. Such a terminal would suit a remote community, shared with 30 customers each at say $30 per month.

If you need dedicated satellite internet, for services like VoIP which require at least 11kbit/s each way all the time the call is in progress then dedicated continuous information rate service (CIR) is appropriate. Dedicated service is
many times as expensive than shared service but is suitable for internet cafés,
businesses and community ISPs. A VSAT terminal is therefore often shared amongst a community of users to share the cost of the monthly charges.

This is not a price comparison site.  You need to contact
any of the businesses mentioned directly and ask them for prices. All information put in this web site at my discretion and may be deleted at any time if I get complaints.

Operation is in microwave frequency bands called C band (4/6GHz), Ku band (11/14GHz)
and Ka band (20/30 GHz). C band is ideal for heavy rain locations. Ku band is the most popular with dish sizes in the range 60cm – 1.8m diameter.
Widespread consumer oriented Ka band spot-beam services exist in the US and Canada.
Examples are Wildblue and Viasat Exede. In Europe, Ka band preliminary services operated on Hotbird for several years and from Spring 2011 a major
Tooway service has proved popular on KA-SAT at 9 deg east longitude.

Read more in the
Tooway and
KA-SAT forum.  More recently Ka band HYLAS has started operation, with Europe,
Middle East and Africa coverage. Yahsat also provided Ka band spot beam service
in the Middle East and a number of Africa countries. Wide bandwidths are
available for satellite service in Ka band and this combined with satellites
having very many spot beams means reduced costs to end users.  Minimum
tariffs for home users around $30 – $40 per month. Ka band suffers from severe rain
attenuation causing reduced bit rates so occasional outages should be expected.

In equatorial areas (up to +/- 45 deg latitude) O3b has introduced a
revolutionary, medium height, O3b orbit system intended for town ISPs and cell phone trunking, also for relaying massive data files from maritime seismic survey
vessels.  O3b customer sites each have two antennas,
tracking the satellites as they move across the sky from west to east above the equator. Reduced
latency or delay, due the reduced distance to medium orbit height is a key selling point.
